Description
Introduction
UHF Wireless Microphone, Panvotech dual vocal handheld mic system with portable mini receiver (1/4 inch plug) for Karaoke,
On-stage performance, DJ, Teachers, Singing, Church, Party, Events.
This Wireless Handheld Mic produces clear & crisp sound with stable performance. Automatic frequency pairing makes it easy to
setup, just play and go. The receiver with 1/4 inch (6.35mm) plug is compatible to any device with 1/4 inch “MIC IN” jack. And the
included1/4-1/8-inch adapter can also be used for device with 1/8-inch mic jack. Ideal for conference speech, presentation,
outdoor events, Recreational Vehicle party, vocal recording, home karaoke, etc.
Key Features
1. OUTSTANDING SOUND & STABLE PERFORMANCE - Crystal clear sound & solid build wireless handheld mic with rechargeable receiver
working range up to 30M (100ft) with stable wireless transmission
2. FULL COMPATABILITY- The 1/4” inch plug wireless receiver is compatible with any sound device(PA, amplifier, mixer, DJ
controller, active speaker, camera, computer, karaoke machine) with 1/4 inch MIC IN input
3. MULTI APPLICATIONS - Ideal for home or car karaoke, classroom activities, church, wedding host, voice projection, outdoor or on
stage performance, enjoy your charming voice with this wireless mic
4. MULTI SELECTABLE FREQUENCIES – The wireless mic system is preset with 8-100 selectable UHF frequencies (varies by region), less
prone to interference and low distortion, thus to use its best performance
5. EASY SETUP & OPERATE - Plug and Play, cable-free, frequency automatic pairing, AA battery powered handheld mic and rechargeable
mini receiver makes it portable, versatile and easy to use
Specification
|
Modulation Mode |
Digital Frequency Modulate |
|
Frequency Range |
UHF 500~900MHz |
|
Channel |
Dual Channel |
|
Preset Frequencies |
8 selecatble frequenciies (One-Key auto paring) |
|
Frequency Response |
75Hz~18kHz ± 3dB |
|
Max. Deviation Range |
±50kHz (with level limiting) |
|
T.H.D. |
< 1.0% @ 1kHz |
|
S/N |
>98dB |
|
Working Range |
Up to 50m |
|
RF Carrier Stability |
±0.005% (-10℃-50℃) |
Mini Receiver (UK-220R)
|
Audio Interface |
6.35 mm Jack |
|
Charging Interface |
Mini USB |
|
Dimension |
64 x 32 x 17 mm (Jack included) |
|
Battery Duration |
4 hrs for 2CH, 6 hrs for 1CH |
|
Recharging Time |
About 1 hour (5V/1A) |
Handheld Microphone (UR-40H, With screen on mic)
|
Carrier Frequency Power |
30mw |
|
Dimension |
246 x φ 53 mm |
|
Cartrdge Type |
Dynamic |
|
Power Supply |
2 x AA Size |
|
Working Time |
Up to 10 hrs |
Handheld Microphone (UK-10H, Without screen on mic)
|
Carrier Frequency Power |
30mw |
|
Dimension |
246 x φ 53 mm |
|
Cartrdge Type |
Dynamic |
|
Power Supply |
2 x AA Size |
|
Working Time |
Up to 10 hrs |
Handheld Microphone (UK-20H)
|
Carrier Frequency Power |
30mw |
|
Dimension |
163 x φ 40 mm |
|
Cartrdge Type |
Dynamic |
|
Power Supply |
2 x AA Size |
|
Charging Interface |
Mini USB or Charging Cradle |
|
Working Time |
Up to 6 hrs (2000 mah, Ni/MH) |
Handheld Microphone (UK-30H)
|
Carrier Frequency Power |
30mw |
|
Dimension |
210 x φ 50 mm |
|
Cartrdge Type |
Dynamic |
|
Power Supply |
2 x AA Size |
|
Working Time |
Up to 6 hrs (2000 mah, Ni/MH) |
