Description
Key Features
1. Stage performance to home use.
2. Single channel wireless microphone system
3. IR auto scan & ACT channel sync setup
4. Working at low interference UHF band (600-865MHz)
5. LCD display working status on both receiver and transmitter
6. Smart handheld microphone and rugged half rack size receiver.
7. Reliable SMT technology
8. Dual filter design makes better anti-interference ability
9. External TNC rubber antenna
10. High performance capsule
11. Balanced and line output available.
Specifications
|
Carrier Frequency
|
UHF560-960MHz
|
|
Audio Frequency Response
|
40Hz-15 kHz ± 3dB
|
|
Dynamic Range
|
>100dB
|
|
THD
|
<1.0%
|
|
Working Range
|
>100m
|
Transmitter
|
Max. Transmission Power
|
9 mW
|
|
Max. Deviation
|
± 40kHz
|
|
Channels
|
200 CHANNELS
|
|
Battery
|
3V (1.5V AA x2)
|
|
Continuous Working Time
|
Up to 8 hours
|
Receiver
|
Power Supply
|
DC 12V/ 800mA
|
|
Power Consumption
|
9W
|
|
Receiving Sensitivity
|
22dBuV
|
|
Dimensions
|
212 x 180 x 44 mm
|
